160x160x60mm pcb enclosures waterproof plastic enclosures china
- Designed to IP65 of IEC60529.
- Silicone rubber gasket makes this ideal for outdoor use in a wide
range of adverse conditions
- Captive steel screws thread into brass inserts for cover on/cover
- Plastic PCB mounting bosses are standard
- Durable, high impact ABS, PC raw material
- The Min.average wall thickness is 3mm
- Gray cover and transparent cover are available
- Assembly includes base, gasket, cover, and 4 steel enclosure screws
- Custom requirements are available.
- Accept OEM order as per your design.
|Material||ABS, PC, Flame retardant, UV stabilized|
|Flame rating||UL 94-HB, UL94-V2, UL94-V0, UL94-5VA|
|Temperature Range||-20°C~80°C(ABS), -40°C~100°C (PC)|
|Impact resistant||IK07(ABS), IK08(PC)|
(might have tolerance)
